Product specifications
| Imperial size | Inner diametermm | Outer diametermm | Lengthm/roll | Working pressure at 23°CMPa | Burst pressure at 23°CMPa | Weightkg/roll | Packing outer diametermm | Packing heightmm | Volumem³ |
|---|---|---|---|---|---|---|---|---|---|
| 5/16 | 8 | 13 | 100 | -0.1–1.1 | 3.3 | 13 | 400 | 200 | 0.032 |
| 3/8 | 9 | 15 | 100 | -0.1–1.1 | 3.3 | 18 | 480 | 180 | 0.041 |
| 1/2 | 12 | 18 | 100 | -0.1–1.0 | 3.0 | 22.6 | 540 | 180 | 0.052 |
| 5/8 | 15 | 22 | 100 | -0.1–1.0 | 3 | 32 | 600 | 235 | 0.084 |
| 3/4 | 19 | 26 | 50 | -0.1–1.0 | 3 | 19.6 | 610 | 160 | 0.061 |
| 1 | 25 | 33 | 50 | -0.1–0.7 | 2.5 | 29 | 660 | 220 | 0.1 |
| 1-1/4 | 32 | 41 | 40 | -0.1–0.7 | 2.0 | 33 | 750 | 250 | 0.141 |
| 1-1/2 | 38 | 48 | 40 | -0.1–0.6 | 1.8 | 41 | 740 | 300 | 0.164 |
| 1-3/4 | 45 | 56 | 40 | -0.1–0.6 | 1.7 | 54 | 850 | 290 | 0.21 |
| 2 | 50 | 62 | 40 | -0.1–0.5 | 1.6 | 63 | 930 | 340 | 0.3 |
| 3 | 75 | 92 | 20 | -0.1–0.4 | 1.3 | 67 | 1020 | 280 | 0.3 |
| 3-1/2 | 90 | 108 | 20 | -0.1–0.4 | 1.2 | 85 | 1100 | 440 | 0.532 |
| 4 | 100 | 118 | 20 | -0.1–0.3 | 1 | 93 | 1150 | 360 | 0.475 |
