Suitable for fields such as industry, agriculture, engineering, fisheries, aquaculture, etc Domain, generall used for conveying liquids under working pressure, can also be used as door lock handle sheaths, handicraft packaging, and children's toy accessories
Suitable for fields such as industry, agriculture, engineering, fisheries, aquaculture, etc Domain, generall used for conveying liquids under working pressure, can also be used as door lock handle sheaths, handicraft packaging, and children's toy accessories
This product is lightweight, affordable, soft, elastic, and non-toxic
-5°C~65°C
Dimensions, pressure, temperature, medium, color, marking, packaging, quantity, and supporting documents.
| Imperial size | Inner diametermm | Outer diametermm | Lengthm/roll | Working pressure at 23°CMPa | Burst pressure at 23°CMPa | Weightkg/roll | Packing outer diametermm | Packing heightmm | Volumem³ |
|---|---|---|---|---|---|---|---|---|---|
| 1/4 | 6 | 8 | 100 | 0.5 | 1.5 | 3 | 305 | 130 | 0.012 |
| 5/16 | 8 | 10 | 100 | 0.5 | 1.5 | 3.8 | 335 | 135 | 0.017 |
| 3/8 | 10 | 12 | 100 | 0.5 | 1.5 | 4.6 | 430 | 150 | 0.027 |
| 1/2 | 12 | 15 | 50 | 0.3 | 1 | 4.3 | 420 | 120 | 0.021 |
| 5/8 | 15 | 18 | 50 | 0.3 | 1 | 5.2 | 420 | 130 | 0.029 |
| 3/4 | 19 | 22 | 50 | 0.3 | 1 | 6.5 | 560 | 150 | 0.047 |
| 1 | 25 | 30 | 50 | 0.3 | 0.9 | 17.8 | 660 | 160 | 0.07 |
Automated notifications use email only. WhatsApp and WeChat are public contact options.
Send the application, medium, dimensions, working pressure, temperature and quantity. Include a product name or link if you have a candidate.
Send an inquiry
