STEEL WIRE REINFORECED PVC HOSE

Name: STEEL WIRE REINFORECED PVC HOSE
Brand: VENTURE
SKU: PVC-HOSE-011

It can be widely used in industry, agriculture and engineering to pump and transport water, oil, powder ideal pipe.

Reference content from the current catalog. Final specifications and compliance claims must be confirmed before ordering.

Applications

It can be widely used in industry, agriculture and engineering to pump and transport water, oil, powder ideal pipe.

Characteristics

This product is a PVC hose embedded with steel wire skeleton, light weight, transparent (can see the flow ofobjects in the tube), good resistance to positive and negative pressure. It can maintain its original shape undervacuum and high pressure.

Working temperature

-5°C ~ 100°C

Order confirmation

Dimensions, pressure, temperature, medium, color, marking, packaging, quantity, and supporting documents.

Back to products

STEEL WIRE REINFORECED PVC HOSE

Product specifications

Imperial size	Inner diametermm	Outer diametermm	Lengthm/roll	Working pressure at 23°CMPa	Burst pressure at 23°CMPa	Weightkg/roll	Packing outer diametermm	Packing heightmm	Volumem³
5/16	8	13	100	-0.1–1.1	3.3	13	400	200	0.032
3/8	9	15	100	-0.1–1.1	3.3	18	480	180	0.041
1/2	12	18	100	-0.1–1.0	3.0	22.6	540	180	0.052
5/8	15	22	100	-0.1–1.0	3	32	600	235	0.084
3/4	19	26	50	-0.1–1.0	3	19.6	610	160	0.061
1	25	33	50	-0.1–0.7	2.5	29	660	220	0.1
1-1/4	32	41	40	-0.1–0.7	2.0	33	750	250	0.141
1-1/2	38	48	40	-0.1–0.6	1.8	41	740	300	0.164
1-3/4	45	56	40	-0.1–0.6	1.7	54	850	290	0.21
2	50	62	40	-0.1–0.5	1.6	63	930	340	0.3
3	75	92	20	-0.1–0.4	1.3	67	1020	280	0.3
3-1/2	90	108	20	-0.1–0.4	1.2	85	1100	440	0.532
4	100	118	20	-0.1–0.3	1	93	1150	360	0.475
